| Bike Model |
E300 -2rd |
|
|
|
| ConfRev |
Speed-36V350W16A |
Speed-48V500W13A |
Bafang Torque-36V350W16A
|
Bafang Torque-48V500W13A
|
| Frame Size |
29(27.5)×14" / 16" / 18" |
| Bike Color |
White / MatteBlack / MatteGray |
| Net Weight |
21.7 KG |
22.9 KG |
22.3 KG |
22.6 KG |
| Frame |
E300, alu alloy AL6061&strengthen, Smooth-welding, Inner cables |
| Handelbar Sets |
RS, Alu alloy,Handlebar 31.8*720,Stem 80,Seat post 31.6*350, Clamps 34.9mm QR |
| Fork |
RS, Alu alloy, Coil suspension, Manual-lockout |
| Head Sets |
Alu alloy CNC with sealed Bearings, 44*56mm |
| Derailleur Lever |
SHIMANO M315-8S |
| Rear Derailleur |
SHIMANO TY300 |
| Cranksets |
RS, Alu alloy,Square hole,38T |
RS, Alu alloy,Square hole,38T |
Matching with Torque BB, 38T |
Matching with Torque BB, 38T |
| Cassettes |
SUGEK-8S,11-32T |
| Chain |
SUMC-8S |
| Brake |
RS, hydr.disc(EM power off),160/160
|
RS, hydr.disc(EM power off),160/160
|
TEKTRO-M275, hydr.disc,160/160 |
TEKTRO-M275, hydr.disc,160/160 |
| Hub |
RS, Alu alloy, 2-sealed Bearings, Disc brake |
| Rim |
RS, Alu alloy with Double-wall&Rivets, W24×H19mm |
| Spoke |
SHUNJIU, Circular |
| Tire |
INNOVA, Black, 29/27.5*2.25"
|
| Grips |
Circular 22.2×120mm, PU leather&locking Ring |
| Saddle |
Comfortable for MTB |
| Pedals |
MTB with lubricating |
| Motor |
Hub, LD, Slotted,36V350W |
Hub, LD, Slotted,48V500W |
Hub, Bafang H400B, Slotted,36V350W |
Hub, Bafang H400B, Slotted,48V500W |
| Max Torque |
50 N.m |
60 N.m |
50 N.m |
60 N.m |
| Speed Limit |
25KMh Default (max 35KMh) |
25KMh Default (max 35KMh) |
25KMh Default (max 35KMh) |
25KMh Default (max 35KMh) |
| Pedal Sensor |
Speed (cadence) |
Speed (cadence) |
Torque+Speed(cadence) |
Torque+Speed(cadence) |
| Battery |
18650 Li-ion 576Wh, 36V16A |
18650 Li-ion 624Wh, 48V13A |
18650 Li-ion 576Wh, 36V16A |
18650 Li-ion 624Wh, 48V13A |
| Endurance |
Max, Pedal assist, 100-120KM |
Max, Pedal assist, 100-120KM |
Max, Pedal assist, 100-120KM |
Max, Pedal assist, 100-120KM |
|
Max, Throttle, 55-65KM |
Max, Throttle, 55-65KM |
Max, Throttle, 55-65KM |
Max, Throttle, 55-65KM |
| Charging Time |
5-6 Hours |
5-6 Hours |
5-6 Hours |
5-6 Hours |
| Charger |
3A, DC2.1 |
3A, DC2.1 |
3A, DC2.1 |
3A, DC2.1 |
| HMI |
G51-LCD digital, 0-5 Modes |
G51-LCD digital, 0-5 Modes |
Bafang C080-LCD digital, 0-5 Modes |
Bafang C080-LCD digital, 0-5 Modes |
| Controller |
Intelligent IC & Sine wave |
Intelligent IC & Sine wave |
Torque+Speed Controll |
Torque+Speed Controll |
| Waterproof |
IP X5 |
IP X5 |
IP X5 |
IP56, Waterproof connector |
| Max Load |
130 KG |
130 KG |
130 KG |
130 KG |
