Tern

The LINK A7 offers various functional features such as a 7-speed SHIMANO gear system, customizable telescopic seat post, and a foldable design that allows for easy storage and theft prevention. The bike also has a 20-inch wheel size that is suitable for urban commuting and adjustable settings to fit different riders' needs. Additionally, the third generation of LINK A7 has improvements such as a forged folding stem and a front cargo rack installation point that can be used with other TERN accessories.

Overall, the LINK A7 folding bike seems to be a practical and versatile option for urban commuters looking for a compact yet smooth riding experience. The bike offers various customization options and accessories that can enhance the overall riding experience.

SPECIFICATIONS
GENERAL INFO
SPEEDS:
2 x 9
WEIGHT:
14.8 kg (32.6 lb)
GEAR INCHES:
29" - 115" (2.28 - 9.14 m)
FOLDING SIZE:
44 × 91 × 75 cm (17.3 × 35.8 × 29.5 in)
FOLDING TIME:
10 seconds
FRAME SIZES:
One size
DISTANCE: SEATPOST TO HANDLEBAR:
63 - 70 cm (24.8 - 27.6 in)
DISTANCE: SADDLE TO PEDAL:
79.5 - 105 cm (31.3 - 41.3 in)
SUGGESTED RIDER HEIGHT:
148 - 195 cm (58.3 - 76.8 in)
MAX GROSS VEHICLE WEIGHT:
120 kg (264.6 lb)
MAX LOAD WEIGHT:
105 kg (231.5 lb)
MAX RIDER WEIGHT:
105 kg (231.5 lb)
FRAME
FRAME:
Tern Eclipse, hydroformed aluminum, 3 patented technologies
FORK:
Integrated, hi-tensile steel

COCKPIT
HANDLEPOST:
Tern Physis 3D, 3D forged, 5 patented technologies
STEM:
Tern Andros, adjustable, forged construction, patented technology
HEADSET:
Flux, cartridge bearings, Physis integrated
HANDLEBAR:
Flat bar, 6061-Al
GRIPS/BAR TAPE:
Velo ergonomic, lock-on
SADDLE:
Tern Porter, patented GripPad design
SEATPOST:
SuperOversize, 6061-Al, micro-adjust clamp
SEATPOST CLAMP:
SuperOversize, 6061-Al

BRAKES
FRONT BRAKE:
Shimano, hydraulic disc
REAR BRAKE:
Shimano, hydraulic disc
BRAKE LEVERS:
Shimano, hydraulic disc
BRAKE CABLE & HOUSING:
Shimano

WHEELS
FRONT HUB:
Shimano, Centerlock disc
REAR HUB:
Shimano, Centerlock disc
SPOKES AND NIPPLES:
Stainless steel
RIMS:
Doublewall aluminum, disc only
TIRES:
Schwalbe Spicer, 40-559, puncture protection, Reflex

TRANSMISSION
SHIFTER(S):
Shimano, trigger, 2 x 8 spd
FRONT DERAILLEUR:
Microshift
REAR DERAILLEUR:
Shimano Sora
CRANKSET:
Forged 6061 aluminum crank, 50/34T
CASSETTE/FREEWHEEL:
Shimano, 11-32T, 9 spd
BOTTOM BRACKET:
Cartridge, sealed bearings
CHAIN:
KMC 9 spd
PEDALS:
Folding, alloy body
SHIFTER CABLE & HOUSING:
SP

BELLS & WHISTLES
BELL:
Aluminum
KICKSTAND:
Deluxe center mount
CLIP SYSTEM:
Magnetix 2.0
LUGGAGE SOCKET:
Yes

The Tern Surge is a modern minivelo. It brings together a unique package of small wheel and diamond frame benefits. While it doesn’t fold, it’s got the compact footprint and faster acceleration of a small-wheeled bike. Thanks to its svelte aero frame, it’s competitively lightweight, yet strong and rigid. With deep rims, integrated brifters, and drop bars, it rides and feels like a road bike, just one designed from the ground up for city living.

451 minivelo design for urban maneuverability and portability
Short reach drop bar with Claris STI levers for integrated shifting precision
Smooth welded aero-edge tubing for a bold and aggressive ride
Internal cable routing for clean body lines
Matte black semi-deep rims for rigidity and performance
2 × 8 Shimano Claris drivetrain for speed and versatility
‘Capsule Collections’ for unique limited-edition variants

Suggested Rider Height:

1）Baghdad 紅色-47cm (B914-0691)

2）Silver 銀色 - 47CM (B914-0689)

General Info
Speeds:
2 × 8
Weight:
10 kg (22 lb)
Gear Inches:
27" - 94" (2.16 - 7.47 m)
Frame Sizes:
47 cm; 52 cm
Max Load Weight:
110 kg (242.5 lb)
Frame
Frame:
Tern x Kitt design Alloy Aero smooth-welding, cable internal / Reflective Decal
Fork:
Tern x Kitt design Alloy Aero-straight blade fork
Cockpit
Stem:
3D Forged Alloy Threadless, ø31.8, 460:80mm / 500:90mm
Headset:
Threadless, semi-integrated
Handlebar:
Kitt Custom Drop-bar Alloy, ø31.8, 460:380mm /500:400mm
Grips/Bar Tape:
Kitt Custom Pinhole Anti-Slip / black or yellow
Saddle:
Kitt Custom Velo / Black
Seatpost:
3D Forged Alloy, Onepiece, ø27.2 / 300mm
Brakes
Front Brake:
Alloy Forged Caliper Brake
Rear Brake:
Alloy Forged Caliper Brake
Brake Levers:
Shimano, ST-R2000, Claris, STI
Wheels
Front Wheel:
Kitt Custom Crow 3.0 451, 30mm Height, 24H, 100mm
Rear Wheel:
Kitt Custom Crow 3.0 451, 30mm Height, 28H, 130mm
Tires:
CST, 20×1-1/8, F/V, Black
Transmission
Shifter(s):
Shimano, SL-R2000, Claris STI, 2×8 spd.
Front Derailleur:
Shimano, FD-2000, Claris, 2 spd.
Rear Derailleur:
Shimano, RD-2000, Claris, 8 spd.
Crankset:
Kitt Custom, Alloy CNC, 53/39T, 170mm
Cassette/Freewheel:
Shimano, 11-28T
Pedals:
Not included
