| Bike Model |
E5pro-Hub |
|
| ConfRev |
Speed-36V350W10A |
Speed-48V500W10A |
| Frame Size |
29(27.5)×17" / 19" |
| Bike Color |
Black / Red / Orange |
| Net Weight |
19.7 KG |
21.1 KG |
| Frame |
CYCTRAC, E5pro, Alu alloy AL6061&strengthen, Smooth-welding, Inner cables |
| Handelbar Sets |
RS, Alu alloy,Matte,Handlebar 31.8*720,Stem 80,Seat post 31.6*350, Clamps 34.9mm QR |
| Fork |
RS, Alu alloy, Coil suspension, Manual-lockout |
| Head Sets |
Alu alloy CNC, 44*44mm |
| Derailleur Lever |
SHIMANO M315- 8S |
| Rear Derailleur |
SHIMANO TY300 |
| Cranksets |
RS, Alu alloy, Square hole, 38T |
| Cassettes |
SUGEK-8S, 11-32T |
| Chain |
SUMC-8S |
| Brake |
RS, hydraulic disc brake(with EM power off ),160/160mm
|
| Hub |
RS, Alu alloy, 2-sealed Bearings, Disc brake |
| Rim |
RS, Alu alloy with Double-wall&Rivets, W24×H19mm |
| Spoke |
SHUNJIU, Circular |
| Tire |
KENDA, 29/27.5×2.1" |
| Grips |
Circular 22.2×120mm, Locking Ring |
| Saddle |
Comfortable for MTB |
| Pedals |
MTB with lubricating |
| Motor |
Hub, LD, Slotted,36V350W |
Hub, LD, Slotted,48V500W |
| Max Torque |
50 N.m |
60 N.m |
| Speed Limit |
25KMh Default (max 35KMh) |
25KMh Default (max 35KMh) |
| Pedal Sensor |
Speed (cadence) |
Speed (cadence) |
| Battery |
18650 Li-ion 360Wh, 36V10A |
18650 Li-ion 480Wh, 48V10A |
| Endurance |
Max, Pedal assist, 70-90KM |
Max, Pedal assist, 80-100KM |
|
Max, Throttle, 40-50KM |
Max, Throttle, 45-55KM |
| Charging Time |
5-6 Hours |
5-6 Hours |
| Charger |
2A, DC2.1 |
2A, DC2.1 |
| HMI |
G51-LCD digital, 0-5 Modes |
G51-LCD digital, 0-5 Modes |
| Controller |
Intelligent IC & Sine wave |
Intelligent IC & Sine wave |
| Waterproof |
IP X5 |
IP X5 |
| Max Load |
130 KG |
130 KG |
